GS-GWN7002

About this product

The Grandstream GWN7002 is a high-performance Multi-WAN Gigabit VPN router designed for small and medium business deployments, offering flexible WAN/LAN configuration, dual SFP ports, advanced VPN and security features, and cloud management capability.

Overview Summary

Overview

Multi-WAN Gigabit VPN Routers
The GWN7000 Series are Multi-WAN Gigabit VPN routers with built-in firewalls that allow businesses to build comprehensive wired, wireless and VPN networks for one or many locations.

• 1x GbE RJ45 port with IEEE 802.3af/at PoE Input and 2x GbE RJ45 ports with 48V Passive PoE output or IEEE802.3af (GWN7002/GWN7003)
• Supports multiple Gigabit RJ45 ports and Gigabit SFP ports
• Built-in VPN support allows easy access to corporate networks for remote employees
• Multiple WAN ports with load balancing and failover to maximize connection reliability
• Rich firewall features including DDNS, port forwarding, DMZ, UPnP, Anti-Dos, traffic rules, NAT and ALG
• Supports application/protocol monitoring and traffic statistics with Deep Packet Inspection (DPI)
• Advanced QoS to ensure real-time performance of low-latency applicationsSupports application, URL,DNS, and web content filtering to block access from unsecure contents
• Embedded controller can manage itself and up to 150 GWN APs; GWN.Cloud offers a free cloud management platform for unlimited routers and GWN APs

Description

The Grandstream GWN7002 router brings enterprise-level wired networking and VPN capabilities into an SMB-friendly chassis. Featuring 2 SFP ports for fibre or uplink resilience plus 4 gigabit RJ45 ports, all configurable as WAN or LAN, it supports multi-WAN load-balancing and failover to maximise network uptime. Built-in VPN services allow up to 50 simultaneous tunnels, enabling secure remote access or inter-office connectivity. On the security side, the device includes firewall, NAT, ALG, DoS and UDP filtering, along with deep packet inspection and traffic statistics to control bandwidth and prioritise low-latency applications. For large deployments, the GWN7002 also acts as an embedded controller for up to 150 access-points and integrates with Grandstream's cloud management platform for centralised provisioning and monitoring.

Features

• 4 x Gigabit RJ45 ports plus 2 x Gigabit SFP ports offer high-speed wired flexibility and uplink options.
• Dual WAN support with load balancing and automatic failover ensures network resilience.
• Up to 50 concurrent VPN tunnels for secure remote connectivity and site-to-site networking.
• Advanced firewall features including DDNS, port forwarding, DMZ, UPnP, Anti-DoS, NAT, ALG and Deep Packet Inspection (DPI).
• Embedded controller functionality and cloud management via GWN.Cloud or GDMS for centralised network control.
• PoE output ports: certain RJ45 ports support 48 V passive or IEEE802.3af PoE output to power network devices.
• High throughput: NAT routing up to ~2.2 Gbps, IPsec VPN throughput up to ~530 Mbps (depending on configuration).
• Flexible WAN/LAN configuration: all ports may be assigned as WAN or LAN to suit deployment needs.

What's in the Box

• Grandstream GWN7002 Multi-WAN Gigabit VPN Router
• Power adapter (100-240 V AC input) and country-specific cord
• Ethernet network cable
• User guide / quick installation guide

Specifications

• Model: GWN7002
• CPU: Dual ARM Cortex-A53, 1 GHz
• Memory: 256 MB RAM, 256 MB Flash
• Maximum NAT sessions: 30 000
• WAN/LAN interfaces: 4 x Gigabit RJ45 (WAN/LAN configurable), 2 x 2.5 Gigabit SFP (uplink/fibre)
• PoE Output ports: 2 x RJ45 support 48 V passive or IEEE802.3af PoE output
• Max NAT throughput: ~2.2 Gbps
• IPsec VPN throughput: ~530 Mbps
• Max VPN tunnels: Up to 50 concurrent tunnels
• Management: Web UI, embedded controller for up to 150 GWN APs, cloud-managed via GWN.Cloud/GDMS

• Security features

  Firewall (DDNS, DMZ, Anti-DoS), Deep Packet Inspection (DPI), traffic monitoring and filtering
• Power supply: 24 V DC (typical); PoE budget depends on port configuration
• Operating temperature: 0 degreesC to 40 degreesC
• Storage temperature: -30 degreesC to 60 degreesC
• Dimensions (approx): 210 x 130 x 35 mm
• Weight (unit): ~505 g

FAQ

How many VPN tunnels can the GWN7002 support?

The GWN7002 supports up to 50 concurrent VPN tunnels, making it suitable for secure remote access and site-to-site connectivity.

Can the ports on the GWN7002 be configured as either WAN or LAN?

Yes. The four Gigabit RJ45 ports and the two SFP uplink ports are configurable as WAN or LAN, giving great flexibility in how the router is deployed within a network.

Does the GWN7002 provide PoE output to other devices?

Yes. Two of the RJ45 ports support 48 V passive or IEEE802.3af PoE output, allowing the router to power compatible network devices such as access points or cameras.

Is cloud management supported?

Yes. The router includes an embedded controller that can manage up to 150 GWN wireless access points and supports cloud-based management via GWN.Cloud and GDMS platforms for easy remote provisioning and monitoring.
