DS-2CE10DF3T-LPXTS-2.8MM

Overview

This Hikvision 2MP two way audio fixed mini bullet analogue camera is designed for dependable indoor and outdoor surveillance where clear video and active deterrence matter. Delivering full HD 1920 x 1080 resolution, it captures sharp detail day and night while supporting both PAL and NTSC signal systems for flexible integration. With smart hybrid lighting that combines infrared and white light, the camera adapts to changing environments to maintain visibility in low light conditions. Built-in audio, alarms, and advanced image processing make it a practical choice for homes, small businesses, and perimeter monitoring.

Description

The camera combines full HD video with real time two way audio, allowing users to see, hear, and speak through a single compact device. Integrated white light and infrared illumination support color and black and white night imaging, while audible and flashing light alarms help deter intruders. Advanced noise reduction and wide dynamic range ensure clear images and intelligible audio in challenging lighting and sound conditions. Its weather sealed housing makes it suitable for reliable year round outdoor use.

Features

Clear imaging in all lighting conditions
High quality imaging is achieved through a 2 MP sensor with a 1920 x 1080 maximum resolution, delivering crisp detail for everyday monitoring. Wide dynamic range technology helps balance scenes with strong backlighting, ensuring subjects remain visible even when light levels vary dramatically. Digital noise reduction further enhances clarity by minimizing grain and motion blur, especially at night.

Smart lighting and night visibility
Smart hybrid lighting gives users flexibility by combining infrared and white light illumination depending on the situation. Infrared lighting reaches up to 25 meters for discreet night monitoring, while white light extends up to 20 meters to provide visible illumination and color images after dark. This dual lighting approach improves situational awareness and supports active deterrence when needed.

Two way audio and active deterrence
Built in microphone and speaker enable real time two way communication over a coaxial connection, making it easy to interact with visitors or warn intruders. AI noise reduction, echo cancellation, and automatic gain control work together to deliver clear and balanced audio. For added security, the camera includes audible alarms and red and blue flashing lights to draw attention and discourage unwanted activity.

Reliable outdoor protection
Designed for durability, the camera features an IP67 rated housing that resists water and dust, making it suitable for outdoor installations. Its compact mini bullet form factor allows for flexible mounting while maintaining a discreet appearance. This robust construction ensures consistent performance in a wide range of weather conditions.

Key technical details

• 2 MP analogue camera with 1920 x 1080 resolution and HD analog output
• 2.8 mm fixed lens with wide field of view
• Built in microphone and 2 W speaker for two way audio
• Infrared range up to 25 m and white light range up to 20 m
• Image enhancements including WDR, BLC, HLC, 3D DNR, and wide dynamic range
• Audible alarm and red and blue flashing light alarm
• IP67 rated protection for outdoor use

Available variants
This model is available with different lens options to suit various coverage needs, including 2.8 mm and 3.6 mm versions under the DS-2CE10DF3T-LPXTS series.

Specifications

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	DS-2CE10DF3T-LPXTS-2.8MM
Camera
Image Sensor	2 MP CMOS
Max. Resolution	1920 (H) x 1080 (V)
Min. Illumination	0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time	PAL: 1/25 s to 1 / 50,000 s , NTSC: 1/30 s to 1 / 50,000 s
Day & Night	ICR
Angle Adjustment	Pan: 0degrees to 360degrees, Tilt: 0degrees to 90degrees, Rotate: 0degrees to 360degrees
Signal System	PAL/NTSC
Slow Shutter	Max. 16 times
Lens
Lens Type	2.8 mm, 3.6 mm fixed focal lens
Focal Length & FOV	2.8 mm, horizontal FOV: 105degrees, vertical FOV: 56degrees, diagonal FOV: 126degrees
	3.6 mm, horizontal FOV: 84degrees, vertical FOV: 46degrees, diagonal FOV: 98degrees
Lens Mount	M12
Microphone
Pickup Distance	In a radius of up to 5 m
Amount	1
Speaker
Rated Power	2 W
Speaker Range	In a radius of up to 5 m
Functions
Audio Function	Echo Cancellation, AI Noise Reduction, Automatic Gain Control
Illuminator
Supplement Light Type	White Light
Supplement Light Range	IR: Up to 25 m
	White Light: Up to 20 m
Image Parameters Switch	STD/HIGH-SAT/HIGHLIGHT
Image Settings	Brightness, Contrast, Sharpness, Anti-banding, AGC
Frame Rate	TVI: 1080p @25 fps/30 fps
Day/Night Mode	Auto/Color
Wide Dynamic Range (WDR)	≥120 dB
Image Enhancement	WDR
	BLC
	HLC
	Global
	HLS
Noise Reduction	3D DNR
White Balance	Auto
	Manual
Interface
Video Output	1 HD analog output
Event
Light Alarm	Flashing Light Alarm (Red and Blue)
Audible Alarm	Yes
General
Power	12 VDC ± 25%, max. 8.7 W
	*You are recommended to use one power adapter to supply the power for one camera. If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.
Material	Plastic
Dimension	179 mm x 69.08 mm x 65.98 mm (7.05" x 2.72" x 2.60")
	Approx. 280 g (0.62 lb.)
Operating Condition	-40 degreesC to 60 degreesC (-40 degreesF to 140 degreesF). Humidity 90% or less (non-condensing)
Communication	HIKVISION-C
Language	English
Approval
Protection	IP67
